Diamond Shower Room Details
| Regular size | 900*900*2000mm |
| standard height | 2000mm |
| glass thickness | 8/10mm |
| Hardware material | 304 stainless steel |
| Hardware color | Matte Black/Gun Grey/Brushed Gold/Mirror Light |
| glass craft | According to customized requirements |
| Standard handle | KLS-199(f hole distance: 440mm) |
| Stone base size | Width≥60mm |
| Graphic description | The movable door can be opened inside and outside, and the direction of opening the door: left/right. Minimum consumption area: 2.5m |
| Size customization range | |
| H | 1850-2500mm |
| L | 900-1600mm |
| W | 800-1300mm |
| Other custom requirements | |
| *Customizable to the top | |
| *Customized glass craftsmanship | |
Feature:
The Diamond Shower Room is stainless steel all-inclusive frame invisible shaft diamond-shaped two solid one live inside and outside open shower room.
Processing Way:
1. Paint baking process: There are three layers of primer and one layer of finish paint. Finally, it is dried at high temperature. Compared with ordinary painting, the surface is smoother, without lines and orange peel, which is not easy to fall off.
2. Polishing process: Electrochemical polishing is adopted, and small parts are polished by water mill. The mirror effect reaches 12K, the mirror luster is long-lasting and bright, and the corrosion resistance is better.
3. Electroplating process: vacuum plating is adopted, the coating adhesion is stronger, and the electroplating coating is thicker.
Material introduction:
1. Ultra white explosion-proof glass, laminated explosion-proof glass and 3D printing laminated glass: The iron content of the glass is about 1/10 of that of ordinary glass. The light transmittance is greater than 91.5%. It is UV resistant, low temperature resistant -192 ° C and high temperature resistant 260 ° C. 5x5cm area, about 70 particles after crushing, 45 particles higher than the industry standard
2. Tape magnetic stripe: Use PP material (ordinary PE material) and add anti-oxidation material PTFE (polytetrafluoroethylene), not easy to yellowing and aging.
3. Explosion proof membrane: Diamond antibacterial explosion-proof film, hardness up to 4h.
4. 304 stainless steel: The content of chromium is more than 18%, and the content of nickel is more than 8%, which is not easy to rust and corrosion-resistant.
5. Pulley: ① 304 stainless steel bearing, not easy to rust. ② Peek nano super wear-resistant polymer is added to the wheel rubber for wear resistance and noise reduction.
Glass Introduction
Hardware colors
Stone base regular colors
Standard measurements of Diamond Shower Room
Diamond Shower Enclosure Cases
FAQ
Q: What is your factory product range?
A: Aluminum door&window, curtain walls, aluminium louver, aluminium cabinets, metal railings, bathroom enclosure.
Q: Do you inspect the finished products? A: Of course we do. The finished products are 100% inspected by QC department before shipping.
Q: Does OEM/ODM is available for your company? A:Yes,OEM/ODM is available and welcomed for our company. We put a lot of resources into innovation as well as research & development, and that makes our company become more competitive.
Q: What's your delivery time? A: It depends on your order. Usually 15-45 days for different products and quantity.
